Venturi for Bag Filter Systems

Venturi for Bag Filter Systems Specification

Usage & Applications
Industrial Bag Filter Systems, Dust Collection Systems, Air Pollution Control

Efficiency
Up to 99.5% for Dust Separation

Automation Grade
Manual/Automatic (as part of system)

Air Flow
Up to 50000 m3/h or as required

Temperature
Up to 350C

Orientation
Vertical/Horizontal

Product Type
Venturi for Bag Filter Systems

Material
Cast Aluminium

Cooling System
Air Cooled

Noise Level
Low

Reactor Thickness
Customized as per requirement

Processing Time
Continuous Operation

Capacity
As per Bag Filter Design

Weight
Depends on Size & Material

Dimension (L*W*H)
Customized on Order

Surface
Galvanized / Painted / Polished

Shape
Cylindrical/Conical

Inner Diameter
30 mm to 300 mm (Customized)

Outer Coating
Epoxy or as specified

Design Standards
IS/ASTM norms or as per order

Application Industries
Cement, Power, Metallurgy, Chemical Plants

Connection Flange
Provided as per design

Maximum Gas Velocity
50-80 m/sec

Mounting Type
Flanged, Welded

Corrosion Resistance
High, suitable for harsh environments

Operating Pressure
Ambient to 600 mm WG

Venturi for Bag Filter Systems Trade Information

Minimum Order Quantity
2000 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
10000 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Venturi for Bag Filter Systems

We are an acclaimed name engaged in offering our precious clients a superior quality range of Venturi for Bag Filter System. Our offered range is widely appreciated by our prestigious clients for its precise design and easy installation. This range can also be availed in various sizes, designs, materials and other related specifications. Our provided Venturi for Bag Filter System is manufactured by a team of our adept professionals utilizing quality approved raw materials and advanced technology. Clients can avail this bag venturi from us at competitive prices.

Features:

Precise design
Smooth finish
Dimensional accuracy
Easy installation
1 Years Warranty

Product Type	Venturi Tubes
Material	Cast Iron
Usage/Application	For Bag Filter System
Thickness	5mm
Hardness	40 HRC

Venturi for Bag Filter Systems
MOC: MS, CI, SS, Aluminium
Plant: Cement, Steel, Power, Refectory, Rice Mill etc

Advanced Customization for Every Industry

Our Venturi components offer tailored solutions with customizable sizes-inner diameters ranging from 30 to 300 mm and reactor thickness per order. The flexibility in orientation (vertical or horizontal) ensures integration across various bag filter system designs, allowing seamless adaptation for cement, power, metallurgy, and chemical industries.

Robust Performance Under Extreme Conditions

With a solid cast aluminium build and high-grade surface finishes, these Venturis provide efficient dust separation and withstand pressures up to 600 mm WG and temperatures to 350C. Their air-cooled systems, noise-reducing features, and corrosion-resistant coatings make them reliable for continuous operation in harsh environments.

Compliant with Stringent Standards

Each Venturi meets IS/ASTM or customer-defined standards, ensuring compatibility with a wide variety of filtration systems. The flanged or welded mounting options, along with flexible process integration (manual or automatic operation), translate to straightforward deployment and reliable performance in dust collection and air pollution control applications.

FAQ's of Venturi for Bag Filter Systems:

Q: How is the Venturi for Bag Filter Systems installed within existing filtration setups?

A: The Venturi can be mounted using flanged or welded connections, depending on your system's requirements. Its dimensional flexibility and customizable features ensure straightforward integration into both new and retrofit bag filter systems.

Q: What are the advantages of using a Venturi with high corrosion resistance in industrial environments?

A: High corrosion resistance, achieved through robust materials and coatings like epoxy, ensures reliable long-term performance, minimizes maintenance needs, and extends the operational life of the Venturi, especially in aggressive industrial conditions.

Q: When should a customized Venturi inner diameter or reactor thickness be specified?

A: Customized inner diameters (from 30 mm to 300 mm) and reactor thicknesses are selected during the design phase to match your system's air flow and capacity requirements, ensuring peak dust separation efficiency and proper system fit.

Q: Where are these Venturis most commonly applied?

A: These Venturis are widely used in industrial bag filter and dust collection systems across sectors such as cement production, power generation, metallurgy, and chemical processing, where effective air pollution control is crucial.

Q: What is the typical process for ordering a Venturi with specific design requirements?

A: Customers provide their design specifications-dimensions, material, operating conditions, and surface finish-during the inquiry stage. The manufacturer then customizes the Venturi, adhering to IS/ASTM or client-requested standards, and supplies units ready for installation.

Q: How does using a Venturi enhance the overall efficiency of dust separation in bag filter systems?

A: The specialized shape and design of the Venturi accelerate the gas stream, facilitating effective dust particle separation and enhancing collection efficiency-reaching up to 99.5%. This guarantees optimal operation of bag filter systems with minimal dust leakage and low noise levels.
